1.7 kg (20x20x20 cm)

Cartridge GA-00-0047

GA-00-0047
New
In Stock (11 Items)
€95.72
Tax excluded Delivered within 3-8 days

703890-0002, GA-00-0047, GT15-019, GT15-230

Cartridge GA-00-0047 for turbos 454183-0001, 454183-0002, 454183-0003, 454195-0001, 454232-0001, 454232-0003, 454232-0004, 454232-0005, 454232-0007, 454232-0009.

See below for more info

GA-00-0047

Brand: TurboCentras
Reference: GA-00-0047

Part numbers

GHP: 703890-0002
TCP: GA-00-0047
EEC: GT15-019
TCO: GT15-230

Used in turbochargers

Garrett 454183-0001 GT17
Garrett 454183-0002 GT17
Garrett 454183-0003 GT17
Garrett 454195-0001 GT17
Garrett 454232-0001 GT17
Garrett 454232-0003 GT17
Garrett 454232-0004 GT17
Garrett 454232-0005 GT17
Garrett 454232-0007 GT17
Garrett 454232-0009 GT17
Garrett 701855-0001 GT17
Garrett 701855-0003 GT17
Garrett 713672-0001 GT17
Garrett 713672-0002 GT17
Garrett 713672-0003 GT17
Garrett 713672-0004 GT17
Garrett 713672-0005 GT17
Garrett 713672-0006 GT17
Garrett 713672-0007 GT17
Garrett 768329-0001 GT17
Garrett 768329-0003 GT17
Garrett 768331-0001 GT17
Garrett 768331-0002 GT17
Garrett 768331-0003 GT17

Included parts

Bearing housing GA-01-0089
Shaft and wheel GA-02-0071
Compressor wheel GA-03-0028
Repair kit GA-04-0015
Heat shield GA-05-0013
Back plate GA-08-0005
Actuator clip GR.5
O-ring GT15-202
Gasket oil outlet T-1


GA-00-0047 - Cartridge

Brand: TurboCentras

TurboCentras Reference: GA-00-0047

GA-00-0047 - Alternative numbers

GHP (Garrett original part number): 703890-0002

TCP (TurboCentras part number): GA-00-0047

EEC (E&E CHRA part number): GT15-019

TCO (TurboCentras old part number): GT15-230

GA-00-0047 - Compatibility table

Cartridge GA-00-0047 - Compatible turbochargers
TURBO MAKERTURBO MODELTURBO REFERENCETURBO PART NUMBERTURBO OE NUMBER
GarrettGT1749V454183-0001454183-0001028145702E
GarrettGT1749V454183-0002454183-0002028145702E
GarrettGT1749V454183-0003454183-0003028145702E
GarrettGT1749V454195-0001454195-0001--
GarrettGT1749V454232-0001454232-0001, 454232-5001S038253019, 038253019A
GarrettGT1749V454232-0003454232-0003, 454232-5003S038253019, 038253019A, 03G253016K
GarrettGT1749V454232-0004454232-0004, 454232-5004S038253019, 038253019A
GarrettGT1749V454232-0005454232-0005, 454232-5005S038253019, 038253019A, 038253019AV200
GarrettGT1749MV454232-0007454232-0007--
GarrettGT1749MV454232-0009454232-0009--
GarrettGT1749V701855-0001701855-0001, 701855-5001S028145702P, 1094742, 95VW 9G438 BA, 95VW9G438BA
GarrettGT1749MV701855-0003701855-0003--
GarrettGT1749V713672-0001713672-0001038253019C, 03G253016L
GarrettGT1749V713672-0002713672-0002, 713672-5002S038253019C, 03G253014R, 03G253016L
GarrettGT1749V713672-0003713672-0003, 713672-5003S038253019C, 038253019CV225, 03G253014R, 03G253016L
GarrettGT1749V713672-0004713672-0004, 713672-5004S038253019C, 038253019CV500, 03G253014R, 03G253016L
GarrettGT1749V713672-0005713672-0005, 713672-5005S038253019CV500, 03G253014R, 03G253016L
GarrettGT1749V713672-0006713672-0006, 713672-5006S038253019C, 03G253014R, 03G253016L, 03G253016N
GarrettGT1749V713672-0007713672-0007, 713672-5007S, 713672-9007S038253019C, 03G253014R, 03G253016L, 03G253016N
GarrettGT1749V768329-0001768329-0001, 768329-5001S038253016K, 038253019A, 03G253016K, 38253019
GarrettGT1749V768329-0003768329-0003, 768329-5003S, 768329-9003S038253016K, 038253019A, 03G253016K, 38253019
GarrettGT1749V768331-0001768331-0001, 768331-5001S038253019C, 03G253014R, 03G253016L
GarrettGT1749V768331-0002768331-0002, 768331-5002S038253019C, 03G253014R, 03G253016L
GarrettGT1749MV768331-0003768331-0003, 768331-5003S, 768331-9003S03G253014R
703890-0002, GA-00-0047, GT15-019, GT15-230
95VW9G438BA, 028145702E, 454183-0001, 028145702E, 454183-0002, 028145702E, 454183-0003, 454195-0001, 038253019, 038253019A, 454232-0001, 454232-5001S, 038253019, 038253019A, 03G253016K, 454232-0003, 454232-5003S, 038253019, 038253019A, 454232-0004, 454232-5004S, 038253019, 038253019A, 038253019AV200, 454232-0005, 454232-5005S, 454232-0007, 454232-0009, 028145702P, 1094742, 701855-0001, 701855-5001S, 95VW 9G438 BA, 95VW9G438BA, 701855-0003, 038253019C, 03G253016L, 713672-0001, 038253019C, 03G253014R, 03G253016L, 713672-0002, 713672-5002S, 038253019C, 038253019CV225, 03G253014R, 03G253016L, 713672-0003, 713672-5003S, 038253019C, 038253019CV500, 03G253014R, 03G253016L, 713672-0004, 713672-5004S, 038253019CV500, 03G253014R, 03G253016L, 713672-0005, 713672-5005S, 038253019C, 03G253014R, 03G253016L, 03G253016N, 713672-0006, 713672-5006S, 038253019C, 03G253014R, 03G253016L, 03G253016N, 713672-0007, 713672-5007S, 713672-9007S, 038253016K, 038253019A, 03G253016K, 38253019, 768329-0001, 768329-5001S, 038253016K, 038253019A, 03G253016K, 38253019, 768329-0003, 768329-5003S, 768329-9003S, 038253019C, 03G253014R, 03G253016L, 768331-0001, 768331-5001S, 038253019C, 03G253014R, 03G253016L, 768331-0002, 768331-5002S, 03G253014R, 768331-0003, 768331-5003S, 768331-9003S

Data updated: 2024-04-19 14:13:55
